Plastic Recycling Granules Making Granulator Machine
Home > Products > Plastic Recycling and Compound Machine > Plastic Recycling Granules Making Granulator Machine

Plastic Recycling Granules Making Granulator Machine

    Unit Price: 6000~30000 USD
    Min. Order: 1 Set/Sets
    Packaging: Discuss
    Transportation: Ocean,Land
    Port: Ningbo, China

Product Description

Product Description

Product Application

This Plastic Recycling Granules Making Granulator Machine is for recycling the plastic waste.
The Plastic Waste includes PE and PP. In other words, it can recycle both PE and PP.
The PE and PP should be soft type as film and bag, because the screw is designed for soft waste, and it is equipped with

Main Features

1) Simple structure in linear type ,easy in installation and maintenance.

2) To recycle film and bag, output can be 200 KG ~300 KG per hour

3) Easy loading the crushed film and bags by conveyor, and fast to push them into extruder by forced feeder

4) Screw hardness is very good, so the screw can work long time

5) Fast screen changer. When changing the dirty screen, the machine will not stop, so avoid the waste.

6) Double stages (two extruders) for best gasification purpose

7) Both stages equipped with screen changer to filter out the dirty things with waste

Specification
Model PA140/120
(we have other models for different output and different configruation)
Screw loader
Motor
KW
2.2 KW
Loading screw
mm
Ø250
Height
adjustable
Forced feeder
Motor
KW
2.2 KW
Working way
screw pushing
Main extruder(stage 1)
screw
mm
Ø 140
L/D
20:1
Heating
KW*zone
3 KW*5 zones
Gasification
1 gasification hole
Screen changer
Optional
Asistant extruder (stage 2)
Screw
mm
Ø 120
L/D
10:1
Heating
KW*zone
3*3
Screen changer
included
(hydraulic or motor driving)
Head
30 holes
Water tank
Length
mm
Material
stainless
Water remover
Motor
KW
2.2
Working way
air blowing
Granule cutter
Motor
KW
5.5 KW
Speed adjust
by inverter
Inverter
KW
5.5 KW
Blade
Cylinder type
FAQ

In order to choose a right recycling machine, you should do below market study:


1. What kind of plastic will you recycle?
Generally, plastic includes PE, PP, PVC, PET, PS, PC, etc.

2. Is the waste soft or rigid?
Soft ones as film and bag
Rigid ones as bottles, containers, etc.

3. What is the output you need per hour by one machine?

4. What is the power? 380 V/50HZ, or 220V/60HZ, etc.

Contact us if you need more details on Plastic Recycling Granulator. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Plastic Granules Making Machine、Plastic Recycling Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
